Name: XXX Midget Bolt Kit
Brand: Ti64 Titanium
SKU: Ti232
Price: 1037.50 USD
Availability: OutOfStock

Complete Bolt kit for XXX Midget Chassis

Please allow 2-4 weeks for delivery.

Triple X Midget Bolt Kit

Line	Application	Description	QTY	Ti64 part#
1	Shocks	1/2-20 X 1 1/4	6	1344
2	Radius Rod To Frame	1/2-20 X 1 1/4	5	1344
3	Radius Rod To Axle	1/2-20 X 1 3/8	3	6022
4	Panhard Bar Clamp	1/2-20 X 1 3/4	1	1346
5	Drag Link To Steering Arm	1/2-20 X 2	1	1348
6	Drag Link To Pitman Arm	1/2-20 X 2	1	1348
7	Tie Rod	1/2-20 X 1 3/4	1	1346
8	Shock Mount On Torsion Arm	1/2 ONS	2	6173
9	Radius Rod To Birdcage	1/2-20 X 2 1/2	2	1349
10	Torsion Arm To Birdcage	1/2-20 X 3 1/2	2	1351
11	Steering Arm To Spindle	7/16-20 X 1 3/4	4	1328
12	Steering Arm Thru Brake Mount	7/16-20 X 1 3/4	2	5146
13	Perch Mount To Birdcage	3/8-16 X 1 1/2	2	4782
14	Pitman Arm	3/8-24 X 1 3/4	1	1312
15	Torsion Arm	3/8-24 X 1 3/4	2	1312
16	Torsion Stop	3/8-24 X 1 3/4	2	1312
17	Torsion Stop Adjuster	3/8-16 X 1 1/2	3	6098
18	Steering Clamp	3/8-24 X 1	2	1309
19	Brake Pedal	3/8-24 X 2	1	1313
20	Jacobs Ladder	3/8-24 X 3 3/4	2	3719
21	Frame Cross Bar	3/8-24 X 1 3/4	2	3718
22	Torque Ball Housing	3/8-16 X 7/8	6	3399
23	Torque Tube	3/8 Stud	7	5105
24	Torque Ball Housing Collar	5/16-18 X 1	4	1091
25	Master Cylinder To Frame	5/16-24 X 2	2	5253
26	KSE GEN 2 Mount	5/16-24 X 1	2	1294
27	Upper Steering Mount	5/16-24 X 1 3/4	2	1297
28	Brake Pedal To Master Cyl	5/16-24 X 2 1/4	1	3710
29	Motorplate To Frame	5/16-24 X 2 1/4	6	3710
30	Bumper & Nerf Bar	3/16 X 1 3/8	16	6158
31	Oil Tank Mount	10-32 X 1	2	3826
32	Floor Pan	10-32 X 1/2	8	6163

Plus 59 steel nuts

Weight	3.1 kg
